Key Features
Huawei HG8245Q2 provides these features:
GPON Port
Class B+
Receiver sensitivity: -27dBm
Wavelengths: US 1310 nm, DS 1490 nm
Wavelength blocking filter (WBF)
Flexible mapping between GEM Port and TCONT
GPON: consistent with the SN or password authentication defined in G.984.3
Bi-directional FEC
SR-DBA and NSR-DBA
Ethernet Port
Ethernet port-based VLAN tags and tag removal
1:1 VLAN, N:1 VLAN, or VLAN transparent transmission
QinQ VLAN
Limit on the number of learned MAC addresses
MAC address learning
POTS Port
Maximum REN: 4
G.711A/, G.729a/b, and G.722 encoding/decoding
T.30/T.38/G.711 fax mode
DTMF
Emergency calls (with the SIP protocol)
USB Port
USB2.0
FTP-based network storage
File/Print sharing based on SAMBA
DLNA DMS/UPnP AV (media server)
WLAN
IEEE 802.11 b/g/n (2.4G)
IEEE 802.11 a/n/ac (5G)
3 3 MIMO
Antenna gain: 2 dBi
WMM
Multiple SSIDs
WPS
2.4G/5G concurrent
Air interface rate: 450 Mbps (2.4G); 1300 Mbps (5G)
Smart interconnection
Smart Wi-Fi coverage
SIP/H.248 auto-negotiation
Any port any service
Parental control
L2/L3 forwarding: 1G uplink, 2G downlink
Smart service
Smart Wi-Fi sharing:
Portal/802.1x authentication (V300R015C10)
SoftGRE-based sharing (V300R015C10)
Association of one account with two POTS ports
Smart O&M
IPTV video quality diagnosis (V300R015C10)
Variable-length OMCI messages
Active/Passive rogue ONT detection and isolation
Call emulation, and circuit test and loop-line test
PPPoE/DHCP simulation testing
WLAN emulation
Layer 3 Features
PPPoE/DHCP simulation testing
WLAN emulation
PPPoE/Static IP/DHCP
NAT/NAPT
Port forwarding
ALG, UPnP
DDNS/DNS server/DNS client
IPv6/IPv4 dual stack, and DS-Lite
Static/Default routes
Multiple services on one WAN port
Multicast
IGMP v2/v3 proxy(V300R015C00)/snooping
MLD v1/v2 snooping
Multicast services through Wi-Fi
QoS
Ethernet port rate limitation
802.1p priority
SP/WRR/SP+WRR
Broadcast packet rate limitation
Security
SPI firewall
Filtering based on MAC/IP/URL addresses
Common O&M
OMCI/Web UI/TR069
Dual-system software backup and rollback
Power Saving
Indicator power saving
Scheduled Wi-Fi shutdown
