Product Overview
Compact UHF duplexer for installation in an HR655 repeater.
Product Details
| Manufacturer | Hytera |
|---|---|
| Model / ordering code | DT28 |
| Listed repeater | HR655 |
| Band options | 400–445 MHz or 425–470 MHz |
| Duplex spacing | 9–11 MHz |
| Insertion loss | ≤1.5 dB; typical 1.3 dB |
| Isolation | ≥70 dB |
| Average input power | 35 W |
| Impedance | 50 Ω |
| Connector | SMA female |
| Dimensions | 95 × 154.1 × 27 mm (±1 mm) |
| Weight | 0.5 kg |
| Operating temperature | −30 to +60 °C |
Request a Quote
Contact DAXUN TECHNOLOGIES for pricing and availability. Please include the model and quantity in your enquiry.
