Hytera DS-6210 DMR Trunking Pro Base Station

Hytera DS-6210 DMR Trunking Pro Base Station is a digital trunking base station based on ETSI open standard DMR Tier 3. The focus is on public safety, public utilities, energy, PMR operator, etc. With innovative design, Hytera DMR Trunking Pro Base Station is provided with features such as carrier grade reliability, wide coverage, large capacity and rich functionalities.

Key Features

System Performance
Max. BS Capacity	512
Max. Carrier Capacity per BS(carrier)	16(extendable to 48 carriers at most)
Network Capacity (carrier)	2048
Subscriber Capacity per MSO	100000
LDS Capacity (pcs)	50000
NMC Capacity (pcs)	64
MPT Interconnect (way per gateway)	16
PSTN/PABX Interconnect (way per gateway)	60(2xE1)/30(1xE1)
Group Call Set-up Duration (ms)	<300(within a single MSO)
Max. Number of Interconnected MSOs	≤512
MS Capacity per System	100000

BS Specificaition
Standard Compliance	PDT/DMR
Frequency Range	UHF3：330-400MHz; UHF1：400-470MHz; UHF2：806-941MHz; VHF：136-174MHz
Carrier Capacity	1CH to 16CH(expandable to 48 at most)
Power Supply	DC 48V; AC 220V
Dimensions(H×W×D) mm	42U:600 mm × 700 mm × 2000 mm; 29U:600 mm × 600 mm × 1430 mm
Weight	8-carrier (42U) ≤314 kg(fully configured); 4-carrier (29U) ≤165 kg(fully configured)
Operating Temperature	-15℃～+35℃
Storage Temperature	-40℃～+85℃
IP Rating	IP20
